Chaoya Factory directly supply 17mm Inner Rotor Brushless motors which is a BLDC motor that comes with an inner rotor.The motor has an external hall that makes it easy to regulate the motor's speed and torque. Chaoya Motor is a professional china manufacturer&supplier who mainly focus on BLDC&Gear Motors produced at least 10 years,17mm Inner Rotor Brushless motors operates without using carbon or graphite brushes and runs on permanent magnets that attract and repel the stator's electromagnetic fields.This design results in a more reliable,efficient,and durable motor with longer life and less maintenance than traditional brushed motors.
The 17mm Inner Rotor Brushless motors is a small inner rotor motor with a diameter of 17mm and a length of 28mm. Because of its compact internal structure, the motor does not have a driver inside, but has an external Hall, so the speed and torque of the motor can be easily adjusted. The 17mm inner rotor brushless motor is produced by Chaoya, a China factory specializing in the production of high-quality BLDC and gear motors. The voltage can reach 4V, It is a low-torque and high-speed brushless motor. It operates without the use of carbon brushes, reducing friction in the motor. This design makes 17mm inner rotor brushless motor more reliable, efficient, and durable. Compared with traditional brushed motors, it has a longer service life, less noise, and higher efficiency, less maintenance.17mm internal rotor brushless motors are an excellent choice for a variety of applications due to their high efficiency, low noise, and long life.
Drones: The small size of this motor makes it ideal for powering small and light drones.
Medical Equipment: 17mm inner rotor brushless motor operates quietly and reliably, making it ideal for medical equipment.
Industrial automation:17mm inner rotor brushless motor has high efficiency and reliable operation, and is suitable for various industrial automation applications.
The 17mm internal rotor brushless motor is a reliable and efficient solution for various applications such as drones, medical equipment, industrial automation, etc. What are you waiting for? Welcome new and old customers to come and buy.
Product Parameters
| Model | Operating Voltage(V) | No Load | Maximum efficiency | Maximum Power | Stall | Rotating Direction | |||||||||
| Current (A) | Rotating Speed(RPM) | Torque(mN.M) | current(A) | Rotating Speed(RPM) | Power(W) | Efficiency | Torque(mN.M) | current(A) | Rotating Speed(RPM) | Power(W) | Torque(mN.M) | current(A) | |||
| BL1728 | 4 | 0.06 | 4412 | 1.25 | 0.186 | 3242 | 0.42 | 57% | 2.32 | 0.288 | 2217 | 0.54 | 4.64 | 0.507 | CW/CCW |
