Chaoya is a Chinese factory specializing in the production of gear motors.Our 37mm Spur Gearbox Brushed Motor For Feeder are ideal for agricultural and livestock systems.Our 37mm Spur Gearbox Brushed Motor For Feeder features a 370 brushed DC motor.Our 37mm Spur Gearbox Brushed Motor For Feeder are designed and manufactured to provide the necessary power and torque required by your feeding system.The motor can run at low speed, and can be equipped with an optional encoder to accurately control material timing and quantity.The smart feeder uses a brushed gear motor and has a super -long lifetime (more than 2,000 hours of working time)
Chaoya Factory is a famous Chinese factory that specializes in the production of DC gear motors for many years. Chaoya cooperates with Zhengbang Group, China's leading poultry and pork producer. In order to help improve its feeding system, Chaoya developed and manufactured the 37mm Spur Gearbox Brushed Motor For Feeder , has accumulated rich experience in the field of animal husbandry. The 37mm Spur Gearbox Brushed Motor For Feeder plays a very important role in the automation of Zhengbang's feeding system. The motor is a 370 series brushed DC motor, equipped with a 37mm gearbox. It has high torque and can operate at low speeds. It provides the necessary power and torque to mobile feeders and distributors, making it ideal for a variety of feeding systems.
The main advantages of the 37mm Spur Gearbox Brushed Motor For Feeder are durability and versatility. In terms of durability, our 37mm Spur Gearbox Brushed Motor For Feeder is made of high-quality materials, ensuring it has a long service life (over 2000 hours of working time). They are very reliable and the motor provides a stable power supply ensuring even feed distribution.Versatility is another advantage of our 37mm Spur Gearbox Brushed Motor For Feeder,They are designed for use in a variety of feed management systems, regardless of their structure. This makes them ideal for use in both amateur and professional settings. They provide great flexibility for feed management systems in different environments, making them an ideal addition to any farm or livestock
Feeding systems are vital to the growth and health of livestock and poultry. Automation is making feeding systems more efficient and less cost-effective, and motors play a vital role in this feeding system. Chaoya’s experience in producing motors and cooperation with Zhengbang Group highlights the effectiveness of motors in automating feeding systems. So, if you are looking for a reliable, efficient motor for your feeding system, the 37mm Spur Gearbox Brushed Motor For Feeder is an excellent choice.
| Model | Operating Voltage(V) | No Load | Maximum efficiency | Maximum Power | Stall | Rotating Direction | |||||||||
| Current (A) | Rotating Speed(RPM) | Torque(mN.M) | current(A) | Rotating Speed(RPM) | Power(W) | Efficiency | Torque(mN.M) | current(A) | Rotating Speed(RPM) | Power(W) | Torque(mN.M) | current(A) | |||
| RC370 | 12 | 0.1 | 7500 | 7.37 | 0.626 | 6467 | 5.00 | 66% | 26.75 | 2.009 | 3750 | 10.51 | 53.51 | 3.92 | CW/CCW |
| RC370 | 24 | 0.06 | 5800 | 7.203 | 0.236 | 4625 | 3.489 | 62% | 17.78 | 0.498 | 2900 | 5.4 | 35.56 | 0.93 | CW/CCW |
